Reefs RC Beast 2000 1/5 Scale Servo Winch 144kg

Reefs Beast 2000 1/5 Scale Servo Winch

• High Torque High Speed Brushless Servo
• W/: REEFS SPOOL / REEFS 5TH SCALE HOOK / SYN. LINE / 3S & 4S CONNECTOR
• SUBMARINE WATERPROOF: 7 Point Seals
• Magnetic Angle Sensor
• Pulse Width Modulation Control
• Voltage 7.4V - 16.8V
• Mechanical Angle: No Limit
• Internal: Steel Gears / All CNC Aluminum Casing
• Bearing Type: 5 Ball Bearings /
• Weight: 10oz / 285g / Wires: 22AWG
• Dimension: 2.59 x 1.18 x 2.32 (LWH)
• Torque: 1000oz @ 10v/ 1250oz @11.1v/ 1450oz @12v / 2000 @ 16.8v
• Speed: .11sec @10v/.105sec @11.1v/.10sec @12v/ .09sec @ 14.4v / .08sec @ 16v
• Spline: 15T
• Dead Band Width: 2uSec

• 72kg @ 10v
• 90kg @ 11.1v
• 104.4kg @ 12v
• 144kg @ 16.8v
